Sales of Mo parts, etc
We are selling rare metal materials such as Mo, W and Ta.
Please contact to our sales representative for the details.
W Tungsten Standard scales
Sheet：t0.05～100.0㎜ x ～W1,000mm x ～L2,000mm
Rod：Φ3～500mm
Wire：Φ0.1～3mm
| Item | Size (mm) | ||
|---|---|---|---|
| Plate | Thickness | Max. | 100 |
| Min. | 0.05 | ||
| Width | Max. | 1,000 | |
| Min. | - | ||
| Length | Max. | 2,000 | |
| Min. | - | ||
| Rod | Diameter | Max. | Φ500 |
| Min. | Φ3 | ||
| Length | Max. | 3,000 | |
| Min. | - | ||
| Wire | Diameter | Max. | Φ3 |
| Min. | Φ0.1 | ||
| Length | Max. | according to the requirement | |
| Min. | according to the requirement | ||
Mo Molybdenum Standard scales
Sheet：t0.05～50.0㎜ x ～W600mm x ～L3000mm
Rod：Φ0.8～120mm
Wire：Φ0.02～3.2mm
| Item | Size (mm) | ||
|---|---|---|---|
| Plate | Thickness | Max. | 100 |
| Min. | 0.05 | ||
| Width | Max. | 1,000 | |
| Min. | - | ||
| Length | Max. | 3,000 | |
| Min. | - | ||
| Rod | Diameter | Max. | Φ500 |
| Min. | Φ3 | ||
| Length | Max. | 5,000 | |
| Min. | - | ||
| Wire | Diameter | Max. | Φ3.2 |
| Min. | Φ0.015 | ||
| Length | Max. | according to the requirement | |
| Min. | 1,000 | ||
Ta Tantalum Standard scales
Sheet：t0.03～10.0㎜ x W10～300mm x 100～1,000mmL
Rod：Φ1～100mm
Wire：Φ0.254～1.5mm
| Item | Size (mm) | ||
|---|---|---|---|
| Plate | Thickness | Max. | 50 |
| Min. | 0.03 | ||
| Width | Max. | 1,000 | |
| Min. | 10 | ||
| Length | Max. | 2,000 | |
| Min. | 10 | ||
| Rod | Diameter | Max. | Φ100 |
| Min. | Φ1 | ||
| Length | Max. | 2,000 | |
| Min. | 3 | ||
| Wire | Diameter | Max. | Φ1.5 |
| Min. | Φ0.254 | ||
| Length | Max. | according to the requirement | |
| Min. | according to the requirement | ||
